Material Information
Stay up to date with your materials
Nordson MEDICAL endeavors to provide our customers with the most up-to-date technical information, directly from the resin manufacturer, on the resins we use.
Find material information here that enables you to select the most appropriate products for your particular application including
- Regulatory Data
- Material Data
- Material Saftey Data Sheets (MSDS)
- Typical Resin Properties
- Sterilization Stability
- Stability Information
- Chemical Resistance Information
This information is for reference only. The particular conditions of your use and application of our products are beyond our control. Please test our products in your specific application to determine their suitability. Free samples are available upon request. If you have further questions please contact us.
Technical Information
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| Nylon Regulatory Data | Nylon Material Data | Nylon MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 12,000 |
| Elongation at Break, % | D638 | 300 |
| Tensile Yield Strength, psi | D638 | 12,000 |
| Flexural Modulus, kpsi | D790 | 410 |
| Rockwell Hardness D | D785 | R121 |
| Rockwell Hardness M | — | M79 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 4 |
| Deflection Temp °F @264psi | D648 | 194 |
| Deflection Temp °F @66psi | D648 | 455 |
| Water Absorption, %, 24 h | D570 | 1.2 |
| Izod Impact, (Notched) ft-lb/in | D256 | 1.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Very good; may discolor to brownish hue |
| Ethylene Oxide (EtO) | Very good; some suceptibility to oxidizing agents |
| Autoclave | Excellent |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Satisfactory |
| Acetone | 100% | 50° C | 122° F | Satisfactory |
| Acetophenone | 100% | 24° C | 75° F | Excellent |
| Acetylene | 100% | 24° C | 75° F | Excellent |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Satisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | Satisfactory |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Satisfactory |
| Boric Acid | 7% | 35° C | 95° F | Unsatisfactory |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | Excellent |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Excellent |
| Chlorine Water | Dilute | 23° C | 73° F | Satisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Excellent |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Excellent |
| Chloroform | 100% | 23° C | 73° F | Satisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Excellent |
| Dichlorethylene | 100% | 23° C | 73° F | Satisfactory |
| Ethanol | 95% | 50° C | 122° F | Excellent |
| Ethyl Acetate | 95% | 50° C | 122° F | Excellent |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Satisfactory |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | Unsatisfactory |
| Formaldehyde | 37% | 24° C | 75° F | N/A |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | N/A |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Unsatisfactory |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Satisfactory |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Unsatisfactory |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | Excellent |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Excellent |
| Methylene Chloride | 100% | 23° C | 73° F | Satisfactory |
| Methanol | 100% | 23° C | 73° F | Excellent |
| Nitric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Oxygen | 100% | 24° C | 75° F | Satisfactory |
| Ozone | 100% | 43° C | 110° F | Unsatisfactory |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | Excellent |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Satisfactory |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Unsatisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | Excellent |
| Toluene | 100% | 50° C | 122° F | Excellent |
| Trichloroethylene | 100% | 23° C | 73° F | Satisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -10 Regulatory Data | -10 Material Data | -10 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | N/A |
| Elongation at Break, % | D638 | 40 |
| Tensile Yield Strength, psi | D638 | 9,900 |
| Flexural Modulus, kpsi | D790 | 450 |
| Rockwell Hardness D | D785 | R122 |
| Rockwell Hardness M | — | M89 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | N/A |
| Deflection Temp °F @264psi | D648 | 216 |
| Deflection Temp °F @66psi | D648 | 332 |
| Water Absorption, %, 24 h | D570 | 0.40 |
| Izod Impact, (Notched) ft-lb/in | D256 | N/A |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Compatible up to 1 Mrad |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Very Good |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Unsatisfactory |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | N/A |
| Ammonium Hydroxide | 10% | 23° C | 73° F | N/A |
| Ammonium Hydroxide | 10% | 70° C | 158° F | N/A |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Unsatisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | N/A |
| Chlorine Water | Dilute | 23° C | 73° F | N/A |
| Chlorine Water | Concen. | 23° C | 73° F | N/A |
| Chlorobenzene | 100% | 23° C | 73° F | N/A |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Satisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | N/A |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | N/A |
| Ethyl Acetate | 95% | 50° C | 122° F | N/A |
| Ethylene Glycol | 100% | 23° C | 73° F | Satisfactory |
| Ethylene Oxide | 100% | 24° C | 75° F | N/A |
| Ethylene Oxide | 100% | 79° C | 175° F | N/A |
| Fatty Acids | — | — | — | Excellent |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Excellent |
| Gasoline | 100% | 85° C | 185° F | Satisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | N/A |
| Hydrochloric Acid | 2% | 23° C | 73° F | Satisfactory |
| Hydrochloric Acid | 10% | 25° C | 77° F | Satisfactory |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Unsatisfactory |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Unsatisfactory |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | N/A |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | N/A |
| Methylene Chloride | 100% | 23° C | 73° F | N/A |
| Methanol | 100% | 23° C | 73° F | N/A |
| Nitric Acid | 10% | 23° C | 73° F | N/A |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | N/A |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | N/A |
| Sulfuric Acid | 30% | 23° C | 73° F | Unsatisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | N/A |
| Water | 100% | 79° C | 175° F | N/A |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -1006/-1007 Regulatory Data | -1006/-1007 Material Data | -1006/-1007 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | — | N/A |
| Elongation at Break, % | — | N/A |
| Tensile Yield Strength, psi | — | N/A |
| Flexural Modulus, kpsi | — | N/A |
| Rockwell Hardness D | — | N/A |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | — | N/A |
| Coef. of Linear 10-5 in/in/°F | — | N/A |
| Deflection Temp °F @264psi | — | N/A |
| Deflection Temp °F @66psi | — | N/A |
| Water Absorption, %, 24 h | — | N/A |
| Izod Impact, (Notched) ft-lb/in | — | N/A |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Compatible up to 5 Mrads |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Very Good |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Unsatisfactory |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | N/A |
| Ammonium Hydroxide | 10% | 23° C | 73° F | N/A |
| Ammonium Hydroxide | 10% | 70° C | 158° F | N/A |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Unsatisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | N/A |
| Chlorine Water | Dilute | 23° C | 73° F | N/A |
| Chlorine Water | Concen. | 23° C | 73° F | N/A |
| Chlorobenzene | 100% | 23° C | 73° F | N/A |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Satisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | N/A |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | N/A |
| Ethyl Acetate | 95% | 50° C | 122° F | N/A |
| Ethylene Glycol | 100% | 23° C | 73° F | Satisfactory |
| Ethylene Oxide | 100% | 24° C | 75° F | N/A |
| Ethylene Oxide | 100% | 79° C | 175° F | N/A |
| Fatty Acids | — | — | — | Excellent |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Excellent |
| Gasoline | 100% | 85° C | 185° F | Satisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | N/A |
| Hydrochloric Acid | 2% | 23° C | 73° F | Satisfactory |
| Hydrochloric Acid | 10% | 25° C | 77° F | Satisfactory |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Unsatisfactory |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Unsatisfactory |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | N/A |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | N/A |
| Methylene Chloride | 100% | 23° C | 73° F | N/A |
| Methanol | 100% | 23° C | 73° F | N/A |
| Nitric Acid | 10% | 23° C | 73° F | N/A |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | N/A |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | N/A |
| Sulfuric Acid | 30% | 23° C | 73° F | Unsatisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | N/A |
| Water | 100% | 79° C | 175° F | N/A |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -40 Regulatory Data | -40 Material Data | -40 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | N/A |
| Elongation at Break, % | D638 | 50-100 |
| Tensile Yield Strength, psi | D638 | 10,200 |
| Flexural Modulus, kpsi | D790 | 390 |
| Rockwell Hardness D | D785 | N/A |
| Rockwell Hardness M | — | M69 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 3.1 |
| Deflection Temp °F @264psi | D648 | 345 |
| Deflection Temp °F @66psi | D648 | 358 |
| Water Absorption, %, 24 h | D570 | 0.3 |
| Izod Impact, (Notched) ft-lb/in | D256 | 1.3 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Highly compatible; will discolor to brownish hue |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Excellent |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Excellent |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Barium Sulfide | 100% | 24° C | 75° F | N/A |
| Benzene | 100% | 23° C | 73° F | Unsatisfactory |
| Bleach | 100% | 23° C | 73° F | Excellent |
| Boric Acid | 7% | 35° C | 95° F | N/A |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | N/A |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Satisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Unsatisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Excellent |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Excellent |
| Ethylene Oxide | 100% | 79° C | 175° F | Excellent |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Satisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Excellent |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Satisfactory |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Satisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Satisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | N/A |
| Phenol | 90% | 23° C | 73° F | N/A |
| Phosphoric Acid | 5% | 98° C | 208° F | Excellent |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Steam | — | 120° C | 248° F | Excellent |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -50 Regulatory Data | -50 Material Data | -50 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | — | N/A |
| Elongation at Break, % | — | N/A |
| Tensile Yield Strength, psi | — | N/A |
| Flexural Modulus, kpsi | — | N/A |
| Rockwell Hardness D | — | N/A |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | — | N/A |
| Coef. of Linear 10-5 in/in/°F | — | N/A |
| Deflection Temp °F @264psi | — | N/A |
| Deflection Temp °F @66psi | — | N/A |
| Water Absorption, %, 24 h | — | N/A |
| Izod Impact, (Notched) ft-lb/in | — | N/A |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Very good up to commonly used doses (6 Mrads) |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Not Recommended |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | N/A |
| Acetone | 100% | 50° C | 122° F | N/A |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | N/A |
| Ammonia, Liquid | 100% | 24° C | 75° F | N/A |
| Ammonium Hydroxide | 10% | 23° C | 73° F | N/A |
| Ammonium Hydroxide | 10% | 70° C | 158° F | N/A |
| Barium Sulfide | 100% | 24° C | 75° F | N/A |
| Benzene | 100% | 23° C | 73° F | N/A |
| Bleach | 100% | 23° C | 73° F | N/A |
| Boric Acid | 7% | 35° C | 95° F | N/A |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | N/A |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | N/A |
| Chlorine Water | Dilute | 23° C | 73° F | N/A |
| Chlorine Water | Concen. | 23° C | 73° F | N/A |
| Chlorobenzene | 100% | 23° C | 73° F | N/A |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | N/A |
| Cyclohexanone | 100% | 24° C | 75° F | N/A |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | N/A |
| Ethyl Acetate | 95% | 50° C | 122° F | N/A |
| Ethylene Glycol | 100% | 23° C | 73° F | N/A |
| Ethylene Oxide | 100% | 24° C | 75° F | N/A |
| Ethylene Oxide | 100% | 79° C | 175° F | N/A |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | N/A |
| Gasoline | 100% | 85° C | 185° F | N/A |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | N/A |
| Hydrochloric Acid | 2% | 23° C | 73° F | N/A |
| Hydrochloric Acid | 10% | 25° C | 77° F | N/A |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | N/A |
| Hydrogen Peroxide | 5% | 43° C | 110° F | N/A |
| Isopropanol | 70% | 23° C | 73° F | N/A |
| Kerosene | 100% | 85° C | 185° F | N/A |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | N/A |
| Methylene Chloride | 100% | 23° C | 73° F | N/A |
| Methanol | 100% | 23° C | 73° F | N/A |
| Nitric Acid | 10% | 23° C | 73° F | N/A |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | N/A |
| Phenol | 90% | 23° C | 73° F | N/A |
| Phosphoric Acid | 5% | 98° C | 208° F | N/A |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | N/A |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | N/A |
| Sulfuric Acid | 30% | 23° C | 73° F | N/A |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | N/A |
| Trichloroethylene | 100% | 23° C | 73° F | N/A |
| Water | 100% | 79° C | 175° F | N/A |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -6005 Regulatory Data | -6005 Material Data | -6005 MSDS |
| Test Method/Material Property | ASTM Test Method | Test Results |
|---|---|---|
| Tensile Strength | D638 | N/A |
| Elongation at Break, % | D638 | 375 |
| Tensile Yield Strength, psi | D638 | 4,400 |
| Flexural Modulus, kpsi | D790 | 170 |
| Rockwell Hardness D | D785 | R80-102 |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | N/A |
| Deflection Temp °F @264psi | D648 | N/A |
| Deflection Temp °F @66psi | D648 | 190 |
| Water Absorption, %, 24 h | D570 | 0 |
| Izod Impact, (Notched) ft-lb/in | D256 | 0.5 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Very good to commonly used sterilization doses (6 Mrads) |
| Ethylene Oxide (EtO) | Highly Compatible |
| Autoclave | Limited to 121°C for 20 minutes due to low heat deflection temperatures |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Excellent |
| Acetophenone | 100% | 24° C | 75° F | Satisfactory |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | N/A |
| Ammonia, Liquid | 100% | 24° C | 75° F | Excellent |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Satisfactory |
| Bleach | 100% | 23° C | 73° F | Satisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Excellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | Excellent |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Unsatisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Satisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | Excellent |
| Ethanol | 95% | 50° C | 122° F | Excellent |
| Ethyl Acetate | 95% | 50° C | 122° F | Satisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Unsatisfactory |
| Fatty Acids | — | — | — | Excellent |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Excellent |
| Gasoline | 100% | 85° C | 185° F | Satisfactory |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Excellent |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Satisfactory |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Satisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Excellent |
| Methanol | 100% | 23° C | 73° F | Excellent |
| Nitric Acid | 10% | 23° C | 73° F | Excellent |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | N/A |
| Phenol | 90% | 23° C | 73° F | Excellent |
| Phosphoric Acid | 5% | 98° C | 208° F | Excellent |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Steam | — | 120° C | 248° F | Satisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | Unsatisfactory |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 12,000 |
| Elongation at Break, % | D638 | 300 |
| Tensile Yield Strength, psi | D638 | 12,000 |
| Flexural Modulus, kpsi | D790 | 410 |
| Rockwell Hardness D | D785 | R121 |
| Rockwell Hardness M | — | M79 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 4 |
| Deflection Temp °F @264psi | D648 | 194 |
| Deflection Temp °F @66psi | D648 | 455 |
| Water Absorption, %, 24 h | D570 | 1.2 |
| Izod Impact, (Notched) ft-lb/in | D256 | 1.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Very good; may discolor to brownish hue |
| Ethylene Oxide (EtO) | Very good; some suceptibility to oxidizing agents |
| Autoclave | Excellent |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Satisfactory |
| Acetone | 100% | 50° C | 122° F | Satisfactory |
| Acetophenone | 100% | 24° C | 75° F | Excellent |
| Acetylene | 100% | 24° C | 75° F | Excellent |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Satisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | Satisfactory |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Satisfactory |
| Boric Acid | 7% | 35° C | 95° F | Unsatisfactory |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | Excellent |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Excellent |
| Chlorine Water | Dilute | 23° C | 73° F | Satisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Excellent |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Excellent |
| Chloroform | 100% | 23° C | 73° F | Satisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Excellent |
| Dichlorethylene | 100% | 23° C | 73° F | Satisfactory |
| Ethanol | 95% | 50° C | 122° F | Excellent |
| Ethyl Acetate | 95% | 50° C | 122° F | Excellent |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Satisfactory |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | Unsatisfactory |
| Formaldehyde | 37% | 24° C | 75° F | N/A |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | N/A |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Unsatisfactory |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Satisfactory |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Unsatisfactory |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | Excellent |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Excellent |
| Methylene Chloride | 100% | 23° C | 73° F | Satisfactory |
| Methanol | 100% | 23° C | 73° F | Excellent |
| Nitric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Oxygen | 100% | 24° C | 75° F | Satisfactory |
| Ozone | 100% | 43° C | 110° F | Unsatisfactory |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | Excellent |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Satisfactory |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Unsatisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | Excellent |
| Toluene | 100% | 50° C | 122° F | Excellent |
| Trichloroethylene | 100% | 23° C | 73° F | Satisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -8003 Regulatory Data | -8003 Material Data | -8003 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 4,800 |
| Elongation at Break, % | D638 | 50 |
| Tensile Yield Strength, psi | D638 | 5,700 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R107 |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 5.5 |
| Deflection Temp °F @64psi | D648 | 173 |
| Deflection Temp °F @66psi | D648 | N/A |
| Water Absorption, %, 24 h | D570 | 0.25-0.40 |
| Izod Impact, (Notched) ft-lb/in | D256 | 6.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Withstands up to 5 Mrad doses without yellowing |
| Ethylene Oxide (EtO) | Good |
| Autoclave | Poor; components may distort due to low heat deflection temperatures |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | Satisfactory |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Satisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Satisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Satisfactory |
| Bleach | 100% | 23° C | 73° F | N/A |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Excellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Monoxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Satisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Satisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Unsatisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Unsatisfactory |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | Unsatisfactory |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Satisfactory |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Satisfactory |
| Isopropanol | 70% | 23° C | 73° F | N/A |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Unsatisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Satisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Satisfactory |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Satisfactory |
| Propane | 100% | 23° C | 73° F | Satisfactory |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Satisfactory |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Satisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | Satisfactory |
| Toluene | 100% | 50° C | 122° F | Satisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Satisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -8012 Regulatory Data | -8012 Material Data | -8012 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 4,800 |
| Elongation at Break, % | D638 | 50 |
| Tensile Yield Strength, psi | D638 | 5,700 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R107 |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 5.5 |
| Deflection Temp °F @264psi | D648 | 173 |
| Deflection Temp °F @66psi | D648 | N/A |
| Water Absorption, %, 24 h | D570 | 0.25-0.40 |
| Izod Impact, (Notched) ft-lb/in | D256 | 6.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Compatible up to 5 Mrads |
| Ethylene Oxide (EtO) | Good |
| Autoclave | Not suitable due to low heat deflection temperatures |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | Satisfactory |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Satisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Satisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Satisfactory |
| Bleach | 100% | 23° C | 73° F | N/A |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Excellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Monoxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Satisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Satisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Unsatisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Unsatisfactory |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | Unsatisfactory |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Satisfactory |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Satisfactory |
| Isopropanol | 70% | 23° C | 73° F | N/A |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Unsatisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Satisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Satisfactory |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Satisfactory |
| Propane | 100% | 23° C | 73° F | Satisfactory |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Satisfactory |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Satisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | Satisfactory |
| Toluene | 100% | 50° C | 122° F | Satisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Satisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -81 Regulatory Data | -81 Material Data | -81 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 4,800 |
| Elongation at Break, % | D638 | 50 |
| Tensile Yield Strength, psi | D638 | 5,700 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R107 |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 5.5 |
| Deflection Temp °F @264psi | D648 | 173 |
| Deflection Temp °F @66psi | D648 | N/A |
| Water Absorption, %, 24 h | D570 | 0.25-0.40 |
| Izod Impact, (Notched) ft-lb/in | D256 | 6.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Compatible up to 5 Mrads |
| Ethylene Oxide (EtO) | Good |
| Autoclave | Not suitable due to low deflection temperatures |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | Satisfactory |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Satisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Satisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Satisfactory |
| Bleach | 100% | 23° C | 73° F | N/A |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Excellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Monoxide | 100% | 50° C | 122° F | Satisfactory |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Satisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | N/A |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Satisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Unsatisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Unsatisfactory |
| Fatty Acids | — | — | — | N/A |
| Fluorine | 100% | 23° C | 73° F | Unsatisfactory |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Satisfactory |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Satisfactory |
| Isopropanol | 70% | 23° C | 73° F | N/A |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Unsatisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Satisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Satisfactory |
| Phenol | 90% | 23° C | 73° F | Unsatisfactory |
| Phosphoric Acid | 5% | 98° C | 208° F | Satisfactory |
| Propane | 100% | 23° C | 73° F | Satisfactory |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Satisfactory |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Satisfactory |
| Tetrahydrofuran | 100% | 23° C | 73° F | Satisfactory |
| Toluene | 100% | 50° C | 122° F | Satisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Satisfactory |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -9 Regulatory Data | -9 Material Data | -9 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 10,000 |
| Elongation at Break, % | D638 | 120 |
| Tensile Yield Strength, psi | D638 | 9,200 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R118 |
| Rockwell Hardness M | — | M75 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 3.9 |
| Deflection Temp °F @264psi | D648 | 266 |
| Deflection Temp °F @66psi | D648 | 273 |
| Water Absorption, %, 24 h | D570 | 0.15 |
| Izod Impact, (Notched) ft-lb/in | D256 | 16.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Compatible up to 10 Mrads with minor loss of physical properties; will discolor to yellow-gree hue |
| Ethylene Oxide (EtO) | Highly Compatible |
| Autoclave | Poor; may craze or stress crack due to molding stresses |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Satisfactory |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | N/A |
| Ammonia, Liquid | 100% | 24° C | 75° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | N/A |
| Benzene | 100% | 23° C | 73° F | Unsatisfactory |
| Bleach | 100% | 23° C | 73° F | Unsatisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | N/A |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Unsatisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Satisfactory |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Satisfactory |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Satisfactory |
| Fatty Acids | — | — | — | Satisfactory |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Unsatisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Call |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Satisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Unsatisfactory |
| Phenol | 90% | 23° C | 73° F | N/A |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | N/A |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Water | 100% | 79° C | 175° F | Unsatisfactory |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -9002 Regulatory Data | -9002 Material Data | -9002 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 10,000 |
| Elongation at Break, % | D638 | 120 |
| Tensile Yield Strength, psi | D638 | 9,200 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R118 |
| Rockwell Hardness M | — | M75 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 3.9 |
| Deflection Temp °F @264psi | D648 | 266 |
| Deflection Temp °F @66psi | D648 | 273 |
| Water Absorption, %, 24 h | D570 | 0.15 |
| Izod Impact, (Notched) ft-lb/in | D256 | 16.0 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Excellent up to 10 Mrads with minor loss of physical properties; light violet hue turns clear upon sterilization |
| Ethylene Oxide (EtO) | Highly Compatible |
| Autoclave | Not Recommended |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Satisfactory |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | N/A |
| Ammonia, Liquid | 100% | 24° C | 75° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | N/A |
| Benzene | 100% | 23° C | 73° F | Unsatisfactory |
| Bleach | 100% | 23° C | 73° F | Unsatisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | N/A |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Unsatisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Satisfactory |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Satisfactory |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Satisfactory |
| Fatty Acids | — | — | — | Satisfactory |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Unsatisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Call |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Satisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Unsatisfactory |
| Phenol | 90% | 23° C | 73° F | N/A |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | N/A |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Water | 100% | 79° C | 175° F | Unsatisfactory |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -9010 Regulatory Data | -9010 Material Data | -9010 MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 10,000 |
| Elongation at Break, % | D638 | 120 |
| Tensile Yield Strength, psi | D638 | 9,200 |
| Flexural Modulus, kpsi | D790 | 330 |
| Rockwell Hardness D | D785 | R118 |
| Rockwell Hardness M | — | M75 |
| Shore Hardness D | D2240 | N/A |
| Coef. of Linear 10-5 in/in/°F | D696 | 3.9 |
| Deflection Temp °F @264psi | D648 | 266 |
| Deflection Temp °F @66psi | D648 | 273 |
| Water Absorption, %, 24 h | D570 | 0.15 |
| Izod Impact, (Notched) ft-lb/in | D256 | 16.0 |
| Sterilization Stability | Gamma Radiation | Compatible up to 10 Mrads with minor loss of physical properties; may discolor slightly dependent upon dose/number of cycles |
|---|---|
| Ethylene Oxide (EtO) | Highly Compatible |
| Autoclave | Poor; may craze or stress crack due to molding stresses |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Satisfactory |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | N/A |
| Acetylene | 100% | 24° C | 75° F | N/A |
| Air | 100% | 82° C | 180° F | N/A |
| Ammonia, Liquid | 100% | 24° C | 75° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Unsatisfactory |
| Barium Sulfide | 100% | 24° C | 75° F | N/A |
| Benzene | 100% | 23° C | 73° F | Unsatisfactory |
| Bleach | 100% | 23° C | 73° F | Unsatisfactory |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | N/A |
| Carbon Dioxide | 100% | 50° C | 122° F | N/A |
| Carbon Monoxide | 100% | 50° C | 122° F | N/A |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Unsatisfactory |
| Chlorine Water | Dilute | 23° C | 73° F | Unsatisfactory |
| Chlorine Water | Concen. | 23° C | 73° F | Unsatisfactory |
| Chlorobenzene | 100% | 23° C | 73° F | Unsatisfactory |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Satisfactory |
| Chloroform | 100% | 23° C | 73° F | Unsatisfactory |
| Cyclohexanone | 100% | 24° C | 75° F | Unsatisfactory |
| Dichlorethylene | 100% | 23° C | 73° F | N/A |
| Ethanol | 95% | 50° C | 122° F | Satisfactory |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Satisfactory |
| Ethylene Oxide | 100% | 24° C | 75° F | Satisfactory |
| Ethylene Oxide | 100% | 79° C | 175° F | Satisfactory |
| Fatty Acids | — | — | — | Satisfactory |
| Fluorine | 100% | 23° C | 73° F | N/A |
| Formaldehyde | 37% | 24° C | 75° F | Unsatisfactory |
| Gasoline | 100% | 85° C | 185° F | Unsatisfactory |
| Glucose | Concen. | 24° C | 75° F | N/A |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | N/A |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Call |
| Kerosene | 100% | 85° C | 185° F | Satisfactory |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Unsatisfactory |
| Methanol | 100% | 23° C | 73° F | Satisfactory |
| Nitric Acid | 10% | 23° C | 73° F | Unsatisfactory |
| Oxygen | 100% | 24° C | 75° F | N/A |
| Ozone | 100% | 43° C | 110° F | Unsatisfactory |
| Phenol | 90% | 23° C | 73° F | N/A |
| Phosphoric Acid | 5% | 98° C | 208° F | Unsatisfactory |
| Propane | 100% | 23° C | 73° F | N/A |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | N/A |
| Sodium Chloride | 10% | 23° C | 73° F | N/A |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | N/A |
| Sodium Hydroxide | 10% | 70° C | 158° F | N/A |
| Steam | — | 120° C | 248° F | Unsatisfactory |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | N/A |
| Toluene | 100% | 50° C | 122° F | Unsatisfactory |
| Trichloroethylene | 100% | 23° C | 73° F | Unsatisfactory |
| Water | 100% | 79° C | 175° F | Unsatisfactory |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -9024 Regulatory Data | -9024 Material Data | -9024 MSDS |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -J1A Regulatory Data | -J1A Material Data | -J1A MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 5,400 |
| Elongation at Break, % | D638 | 100-400 |
| Tensile Yield Strength, psi | D638 | 6,500 |
| Flexural Modulus, kpsi | D790 | 360 |
| Rockwell Hardness D | D785 | N/A |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | D76-80 |
| Coef. of Linear 10-5 in/in/°F | D696 | 7.6 |
| Deflection Temp °F @264psi | D648 | 244 |
| Deflection Temp °F @66psi | D648 | N/A |
| Water Absorption, %, 24 h | D570 | 0.015 |
| Izod Impact, (Notched) ft-lb/in | D256 | 3.1 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Highly compatible; will discolor to brownish hue |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Excellent |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | Unsatisfactory |
| Acetylene | 100% | 24° C | 75° F | Excellent |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Excellent |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Exellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | Excellent |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Excellent |
| Chlorine Water | Dilute | 23° C | 73° F | Excellent |
| Chlorine Water | Concen. | 23° C | 73° F | Excellent |
| Chlorobenzene | 100% | 23° C | 73° F | Excellent |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Excellent |
| Chloroform | 100% | 23° C | 73° F | Excellent |
| Cyclohexanone | 100% | 24° C | 75° F | Excellent |
| Dichlorethylene | 100% | 23° C | 73° F | Excellent |
| Ethanol | 95% | 50° C | 122° F | Excellent |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Excellent |
| Ethylene Oxide | 100% | 79° C | 175° F | Excellent |
| Fatty Acids | — | — | — | Excellent |
| Fluorine | 100% | 23° C | 73° F | Excellent |
| Formaldehyde | 37% | 24° C | 75° F | Excellent |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Excellent |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | Excellent |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Excellent |
| Methanol | 100% | 23° C | 73° F | Excellent |
| Nitric Acid | 10% | 23° C | 73° F | Excellent |
| Oxygen | 100% | 24° C | 75° F | Excellent |
| Ozone | 100% | 43° C | 110° F | Satisfactory |
| Phenol | 90% | 23° C | 73° F | Excellent |
| Phosphoric Acid | 5% | 98° C | 208° F | Excellent |
| Propane | 100% | 23° C | 73° F | Excellent |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Steam | — | 120° C | 248° F | Excellent |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | Unsatisfactory |
| Toluene | 100% | 50° C | 122° F | Excellent |
| Trichloroethylene | 100% | 23° C | 73° F | Excellent |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -J2A Regulatory Data | -J2A Material Data | -J2A MSDS |
| Test Method/Material Property | ASTM Test Method | |
|---|---|---|
| Tensile Strength | D638 | 5,000-8,000 |
| Elongation at Break, % | D638 | 20-100 |
| Tensile Yield Strength, psi | D638 | 6,500-8,000 |
| Flexural Modulus, kpsi | D790 | 200-335 |
| Rockwell Hardness D | — | N/A |
| Rockwell Hardness M | — | N/A |
| Shore Hardness D | D2240 | 76-80 |
| Coef. of Linear 10-5 in/in/°F | D696 | 6.6-8.0 |
| Deflection Temp °F @264psi | D648 | 221-239 |
| Deflection Temp °F @66psi | D648 | 257-284 |
| Water Absorption, %, 24 h | D570 | 0.01-0.03 |
| Izod Impact, (Notched) ft-lb/in | D256 | 8-25 |
| Sterilization Stability | |
|---|---|
| Gamma Radiation | Highly compatible; will discolor to brownish hue |
| Ethylene Oxide (EtO) | Excellent |
| Autoclave | Excellent |
| Chemical | % | Temperature° C | Temperature° F | Recommendation |
|---|---|---|---|---|
| Acetic Acid | 5% | 23° C | 73° F | Excellent |
| Acetone | 100% | 50° C | 122° F | Unsatisfactory |
| Acetophenone | 100% | 24° C | 75° F | Unsatisfactory |
| Acetylene | 100% | 24° C | 75° F | Excellent |
| Air | 100% | 82° C | 180° F | Excellent |
| Ammonia, Liquid | 100% | 24° C | 75° F | Unsatisfactory |
| Ammonium Hydroxide | 10% | 23° C | 73° F | Excellent |
| Ammonium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Barium Sulfide | 100% | 24° C | 75° F | Excellent |
| Benzene | 100% | 23° C | 73° F | Excellent |
| Bleach | 100% | 23° C | 73° F | Excellent |
| Boric Acid | 7% | 35° C | 95° F | Excellent |
| Calcium Carbonate | Sat. sol. | 24° C | 75° F | Excellent |
| Carbon Dioxide | 100% | 50° C | 122° F | Excellent |
| Carbon Monoxide | 100% | 50° C | 122° F | Excellent |
| Carbon Tetrachloride | 100% | 50° C | 122° F | Excellent |
| Chlorine Water | Dilute | 23° C | 73° F | Excellent |
| Chlorine Water | Concen. | 23° C | 73° F | Excellent |
| Chlorobenzene | 100% | 23° C | 73° F | Excellent |
| Chlorofluorocarbon 11 | 100% | 24° C | 75° F | Excellent |
| Chloroform | 100% | 23° C | 73° F | Excellent |
| Cyclohexanone | 100% | 24° C | 75° F | Excellent |
| Dichlorethylene | 100% | 23° C | 73° F | Excellent |
| Ethanol | 95% | 50° C | 122° F | Excellent |
| Ethyl Acetate | 95% | 50° C | 122° F | Unsatisfactory |
| Ethylene Glycol | 100% | 23° C | 73° F | Excellent |
| Ethylene Oxide | 100% | 24° C | 75° F | Excellent |
| Ethylene Oxide | 100% | 79° C | 175° F | Excellent |
| Fatty Acids | — | — | — | Excellent |
| Fluorine | 100% | 23° C | 73° F | Excellent |
| Formaldehyde | 37% | 24° C | 75° F | Excellent |
| Gasoline | 100% | 85° C | 185° F | Excellent |
| Glucose | Concen. | 24° C | 75° F | Excellent |
| Glycerin | 100% | 24° C | 75° F | Excellent |
| Hydrochloric Acid | 2% | 23° C | 73° F | Excellent |
| Hydrochloric Acid | 10% | 25° C | 77° F | Excellent |
| Hydrofluoric Acid | 10% | 23° C | 73° F | Excellent |
| Hydrogen Peroxide | 1% | 24° C | 75° F | Excellent |
| Hydrogen Peroxide | 5% | 43° C | 110° F | Excellent |
| Isopropanol | 70% | 23° C | 73° F | Excellent |
| Kerosene | 100% | 85° C | 185° F | Excellent |
| Methyl Ethyl Ketone | 100% | 50° C | 122° F | Unsatisfactory |
| Methylene Chloride | 100% | 23° C | 73° F | Excellent |
| Methanol | 100% | 23° C | 73° F | Excellent |
| Nitric Acid | 10% | 23° C | 73° F | Excellent |
| Oxygen | 100% | 24° C | 75° F | Excellent |
| Ozone | 100% | 43° C | 110° F | Satisfactory |
| Phenol | 90% | 23° C | 73° F | Excellent |
| Phosphoric Acid | 5% | 98° C | 208° F | Excellent |
| Propane | 100% | 23° C | 73° F | Excellent |
| Sodium Bicarbonate | Concen. | 24° C | 75° F | Excellent |
| Sodium Chloride | 10% | 23° C | 73° F | Excellent |
| Sodium Chloride | Sat. sol. | 24° C | 75° F | Excellent |
| Sodium Hydroxide | 10% | 70° C | 158° F | Excellent |
| Steam | — | 120° C | 248° F | Excellent |
| Sulfuric Acid | 30% | 23° C | 73° F | Excellent |
| Tetrahydrofuran | 100% | 23° C | 73° F | Unsatisfactory |
| Toluene | 100% | 50° C | 122° F | Excellent |
| Trichloroethylene | 100% | 23° C | 73° F | Excellent |
| Water | 100% | 79° C | 175° F | Excellent |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -PK5 Regulatory Data | -PK5 Material Data | -PK5 MSDS |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| SAN Regulatory Data | SAN Material Data | SAN MSDS |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| -U71 & -U75 Regulatory Data | -U71 & -U75 Material Data | -U71 & -U75 MSDS |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| AdvantaFlex Regulatory Data | AdvantaFlex Material Data | AdvantaFlex MSDS |
| Regulatory Data | Material Data | MSDS |
|---|---|---|
| Platinum Silicone Regulatory Data | Platinum Silicone Material Data | Platinum Silicone MSDS |
